RUNET software is developing structural design software for Civil engineers and Architects. The programs deal with both finite element and dynamic analysis and utilize CAD and CAM methods.

WOODexpress - structural timber design software - a program for design and dimensioning of timber components, and timber roofs according to Eurocode 5. In a graphic environment you design roof trusses and elements of timber structures. WOODexpress simplifies all the repetitive and time-consuming every day calculations for timber elements and timber roofs. Detailed report with calculations, automatic generation of truss drawings and details of connections.

To design a timber component or truss, choose from ready roof models, specify the main dimensions, loads, design code parameters, and the design is immediately performed and drawings produced automatically. Default values and checks for erroneous input values, facilitate the input data process. The report, which is created simultaneously, shows in detail all the calculations and the design steps with references to the corresponding design code paragraphs. Clear warnings informs you in case of inadequate design.

The material properties, the loads and the design code parameters, timber sections, can be adjusted by the user according to the requirements of the National application document.

More info.

RUNETsoftware is developing structural design software for Civil engineers and Architects. The programs deal with both finite element and dynamic analysis and utilize CAD and CAM methods.

With BETONexpress you can easily design structural elements of reinforced concrete. For each structural element, you specify the basic dimensions, loads and material properties, and you obtain the detailed concrete design in ultimate limit state (ULS), and in serviceability limit state (SLS).

The dimensioning is according to Eurocode 2, EN 1992-1-1:2004, Design of concrete structures, General rules and rules for buildings, with supplement of Eurocode 7, EN 1997-1:2004, Geotechnical design – General rules, for geotechnical analysis (footings, retaining walls), Eurocode 0, EN 1990:2002, for load combinations, and Eurocode 8 for seismic loading.

The last EN versions of the Eurocodes are implemented. You can comute also the capacity of slab, beams and column strengthened with FRP (fibre-reinforced polymers). Regular and light weight aggregate concrete included.

The program's CAD modulus automatic generates detailed drawings of the structure and the reinforcement. A combined detailed report and reinforcing steel schedule is produced for the designed concrete components. Assumptions and references to design codes are shown in the report. The reinforcing steel schedule can be edited with a specialised editor which is included. The user can select the applicable National Annex. The design code parameters, as well as default values, can be adjusted by the user. Design Charts and Tables for use and understanding of Eurocode 2 are included n the program. In addition a set of engineering tools (unit conversion, computation of areas, moments of inertia, standard steel sections etc.) are included in the program.

More link.

PLS-CADD is a line design program that includes all the terrain, sag-tension, loads, clearances and drafting functions necessary for the design of an entire power line.

PLS-POLE analyzes and designs structures with wood, laminated wood, steel, concrete or fiber reinforced polymer poles, or modular aluminum masts.

SAPS - Structural Analysis of Power and communication Systems - is the analysis engine. It can be purchased for standalone use to solve exotic problems. SAPS can act as a plug-in to add finite element sag-tension to the standard edition of PLS-CADD.

TOWER analyzes, designs and optimizes steel lattice towers for transmission and substation applications.

More info.

AgStar - Agricultural & Irrigation Software - offers a complete package of land-leveling tools for agricultural and irrigation purposes. It carries a versatile suite of commands designed to simplify and speed up the professional surveyor’s work, as well as reduce costs by minimizing the amount of dirt to move.

AgStar handles both the survey and the design sides of land-leveling, allowing you to survey large fields with GPS, and then determine the optimal field design requiring the least amount of dirt moved. The field design tool can be set to a user-specified field slope, or to search for the optimal slope. A host of other design parameters can be specified, including cut/fill ratio, amount of dirt to import or export, and constraints on the range of slopes to search. With AgStar, you can also subdivide the field and assign different designs to each subdivision, which is useful if you want crowns in the field.

For data collection, AgStar supports a wide range of GPS RTK receivers, including such popular brands as Navcom, Ashtech, Leica, Sokkia, and Trimble; if you have it, AgStar probably supports it, which means you may not even need to upgrade your hardware.

AgStar runs on IntelliCAD, which is built-in, so there is no need to buy an additional CAD engine to run the software. The new release includes updated GPS drivers for new receivers from John Deere, Ashtech and others. There’s also the ability to work with geo-referenced aerial images and shape files.
