 Автор: Williams
 Дата: 30 сентября 2015
 Просмотров: 1 970 |
| |
Ensoft LPile 2015 v8.03
LPILE is a special-purpose program based on rational procedures for analyzing a pile under lateral loading using the p-y method. LPILE solves the differential equation for a beam-column using nonlinear lateral load-transfer (p-y) curves. The program computes deflection, bending moment, shear force and soil response over the length of the pile.
As an option, components of the stiffness matrix at the pile head may be computed internally by LPILE so users can incorporate basic soil-structure interaction in their super-structure analyses. Another option from LPILE provides graphs of pile-head deflections for various pile lengths, to help users with optimum pile penetrations (for lateral response).
Nonlinear lateral load-transfer from the foundation to the soil is modeled using p-y curves generated internally using published recommendations for various types of soils. Special procedures are programmed for computing p-y curves for layered soils and for rocks. Alternatively, the user can enter manually any other externally generated ip-y curves.
Five types of pile-head boundary conditions may be selected, and the structural properties of the pile can vary as a function of depth. LPILE has analytical features to compute the nonlinear moment-curvature relationships and nominal moment capacity of a pile’s section based on specified pile dimensions and nonlinear material properties. Optionally, the user may enter nonlinear moment-curvature relationships to be used in place of the internally-generated values. LPILE provides several design recommendations for rebar arrangements in drilled shafts. |
| |
Читать статью дальше (комментариев - 18)
| |
|
|
Автор: Williams
Дата: 22 сентября 2015
Просмотров: 4 865 |
| |
Novo Tech Software Mega Pack:
LateraIK v3.23.2012.1212, NovoBPT v1.0.2014.401, NovoCPT v3.32.2014.1209,
NovoFormula v1.41.2013.1127, NovoLab v2.52.2015.816, NovoLiq v3.2.2014.910,
NovoSPT v2.79.2014.1208, PEYSANJ v4.32.2014.515, VisLog v3.2.2015.126
LateralK is used to calculate lateral earth pressure.
NovoBPT is designed for correcting raw BPT blow counts (Nb) and converting them to SPT blow counts (N60).
NovoCPT program is designed for interpretation of cone penetration test data.
NovoFORMULA is used to estimate unknown soil parameters based on known parameters.
NovoLAB is the most comprehensive geotechnical software for lab data management and borehole log drafting.
NovoLIQ software is designed for soil liquefaction analysis and supports variety of field tests.
NovoSPT is a unique geotechnical software designed for correlating SPT blow counts (N) to various soil properties using 300 correlations.
PEYSANJ is designed for bearing capacity and settlement analysis, earth pressure calculation, plate load test and pressure-meter test processing.
Use VisLog to convert your borehole logs to a 3D, interactive model of subsurface soil layers without the hassle of using expensive and complex computer programs.
More info.
|
| |
Читать статью дальше (комментариев - 36)
| |
|
|
